Thursday, 14 May 2015

Sierra Leone Textiles–the Alldridge Collection in Brighton Museum–part two

Brighton Museum and Art Gallery houses more than 100 objects from Sierra Leone purchased in 1899 from Thomas Joshua Alldridge (1947-1916). Alldridge was in Sierra Leone for extended periods between 1871 and 1905,  served as District Commissioner for Sherbro district between 1894 and 1905, travelled extensively throughout much of the country. Among the collection at Brighton are a small but important group of textiles. Sierra Leone textiles are extremely rare and the early dating and provenance makes this perhaps the second ranking group worldwide after those at the British Museum. The accession notes attribute all of them to “Mendiland”, indicating that the weavers were Mende, but given that Alldridge did travel widely in the area over a number of years the possibility that some came from other ethnic groups can not be rules out.

None of the cloths are currently on display but last month I was able to view them with the kind assistance of curators Helen Mears and Martin Pel. Due to the size of the cloths it was not possible to take full view photographs but I was able to get detail pictures that are worth sharing. The three textiles shown here are all display hangings, long and elaborate cloths that would have served as a backdrop for important village events and enhanced the status of the family and chieftaincy that owned them. All three owe a debt to historical links between Mali and Sierra Leone, both in the underlying structure of a blue and white checkerboard layout and in the use of tapestry weave patterning. All are woven from hand spun cotton.

Reference #BMAG.R3483.110a

BMAG.R3483.110adetail1

BMAG.R3483.110adetail2

BMAG.R3483.110adetail3

Reference # BMAG.R3483.110c

BMAG.R3483.110c

BMAG.R3483.110cdetail1

BMAG.R3483.110cdetail2

Reference # BMAG.R3483.110f

BMAG.R3483.110f

BMAG.R3483.110fdetail1

BMAG.R3483.110fdetail2

BMAG.R3483.110fdetail3

BMAG.R3483.110fdetail4

BMAG.R3483.110fdetail5

Click on the photos to enlarge.

Thursday, 7 May 2015

New Exhibition: “African Textiles and Adornment: Selections from the Marcel and Zaira Mis Collection” at LACMA

Untitled-1

Brilliant color, bold patterns, and intriguing symbols characterize the dress of many societies throughout the African continent. Not only are garments visually compelling, but they are also laden with emblems of power that signify the wealth, status, prestige, or even divinity of the bearer. The body’s seat of intelligence, spirit, and identity is also established by crowning the head with spectacular structures fashioned out of feathers or beads that soar above or surround the head, increasing or expanding a subject’s stature.

Featuring over 35 dynamic textiles and commanding headdresses, this exhibition presents the profound visual impact of African textiles. Fashioned in a variety of techniques and enhanced with a broad range of natural materials, these extraordinary garments and headpieces sculpt the body into iconic form and serve as aesthetic surrogates for power and esteem.”

April 5, 2015–October 12, 2015

At: LACMA

A book on this collection was published by 5Continents a few years ago.

Saturday, 25 April 2015

Cloth of the Month: An Ewe Chief’s Robe Cloth

E822

E822 - Very unusual mixed strip Ewe man's cloth with seven different strip designs and exceptionally elaborate borders. The majority of Ewe cloths don't have distinct borders (unlike Asante kente) and on those that do the designs are generally quite repetitive with only subtle variations. Here though the variants in the strip pattern and their interaction with the weft blocks provide the main visual interest in the central field but the borders themselves are markedly more complex with threefold weft blocks framing a great variety of neatly woven weft float motifs.

E822d



This makes the borders themselves a design focus that counter balances the irregular off-beat layout of patterns within the central field.

E822d1

E822d2

Condition - very good, cloth is complete, there is slight discoloration in places on some white strips, probably from decades of storage in a metal trunk. Dates from circa 1900-20s. Measurement: 107 inches x 69 ins, 272cm x 175cm PRICE: Email for price.

Click here to view this cloth on our New Acquisitions Gallery and here for our selection of Ewe cloths.

Wednesday, 22 April 2015

Sierra Leone Textiles–the Alldridge Collection in Brighton Museum–part one.

Brighton Museum and Art Gallery houses more than 100 objects from Sierra Leone purchased in 1899 from Thomas Joshua Alldridge (1947-1916). Alldridge was in Sierra Leone for extended periods between 1871 and 1905,  served as District Commissioner for Sherbro district between 1894 and 1905, travelled extensively throughout much of the country. Among the collection at Brighton are a small but important group of textiles. Sierra Leone textiles are extremely rare and the early dating and provenance makes this perhaps the second ranking group worldwide after those at the British Museum. The accession notes attribute all of them to “Mendiland”, indicating that the weavers were Mende, but given that Alldridge did travel widely in the area over a number of years the possibility that some came from other ethnic groups can not be rules out.

None of the cloths are currently on display but last Monday I was able to view them with the kind assistance of curators Helen Mears and Martin Pel. Due to the size of the cloths it was not possible to take full view photographs but I was able to get detail pictures that are worth sharing. In todays post I will focus on the most spectacular of the group, a cloth that Venice Lamb in her book Sierra Leone Weaving calls “one of the greatest of all West African cloths.” She publishes a full view in black and white, shown below, and for reasons that are not clear to me from the text, attributes it to a weaver of the Vai ethnic group. Its accession number is R3483.110h.

BMAGLamb

Click on the photos to enlarge. The cloth measures 12 foot x 4 foot 7inches (365cm x 104  ) and is woven entirely from hand spun cotton in white, indigo and brown (kola nut dye ?). It is notably for the densely worked and incredibly varied blocks of weft float patterning. It falls into the largest and most complex group of Sierra Leone cloths of a type called kpoikpoi (or kpokpo) and would have been displayed at important events rather than worn.

BMAG.R3483.110hdetai1

BMAG.R3483.110hdetai2

BMAG.R3483.110hdetail3

BMAG.R3483.110hdetail4

BMAG.R3483.110hdetail5

BMAG.R3483.110hdetail6

BMAG.R3483.110hdetail7

BMAG.R3483.110hdetail8

BMAG.R3483.110hdetail9

BMAG.R3483.110hdetail10

Saturday, 18 April 2015

Exhibition and book: “Emblems of Power: Asafo Flags from Ghana” at the African Art Museum of the SMA Fathers

rosen front

On now and through May at the African Art Museum of the SMA Fathers, Tenafly, New Jersey, the exhibition shows the Asafo flag collection of Mary and Paul Rosen and includes two very fine long banners. It is accompanied by a 100 page catalogue by Mary and Paul Rosen that features their photographs of Asafo posuban shrines and is a useful addition to the small group of books on the topic. Price for the catalogue is US$20 plus postage and it is available from Paul Rosen at ppr2001@med.cornell.edu .

rosen back

Thursday, 26 March 2015

Cloth of the month: A fine natural dyed Hausa blanket.

AS523

AS523 - Fine Hausa blanket collected before World War II. Although cloths such as this were doubtless once widely available in the north of Nigeria few examples from this period have survived and they are not well represented in museum collections. Unlike more common examples from the 1960s it is woven from hand spun cotton throughout (by the 1960s weavers were using machine spun cotton for the warp) and the tapestry weave inserts are dyed with natural dyes. This cloth was unused when collected and is in very good condition, dates from the 1930s. Measurement: 97 inches x 57 ins, 246cm x 146cm

AS523d

AS523d1

Click on the photos to enlarge. To see this cloth on our galley click here.

We have just acquired a group of more recent Hausa blankets from the 1960s that will be posted on the gallery in the coming weeks.

Saturday, 21 March 2015

Nkontompo Ntama–The Liar’s Cloth

I first met Claude Delmas a couple of years ago when I gave a talk on African textiles at the Oriental Rug Society here in London and she had brought along several of the cloths she had woven. These turned out to be remarkable reproductions of some of the more unusual West African textile designs, including the intriguing Asante kente pattern known as “liar’s cloth.”  The article we reproduce here with Claude’s kind permission was first published in 2008 in the Journal for Weavers Spinners and Dyers #227 . Having seen a loom set to weave “liar’s cloth” in the collection of the Deutsche Textilmuseum, Krefeld, I can confirm that Claude’s solution to the mystery of this design is the correct one.

lcloth01

“Nkontompo ntama – The Liar’s Cloth

Claude Delmas, London Guild

Looking at John Gillow’s book African Textiles my eye fell on the image of a lovely blue and white strip woven cloth from Ghana decorated with very precise inlay motifs. The caption read: ‘Liar’s Cloth in which blue warp threads are taken down the length of the cloth in stepped fashion’. The picture was so small that I needed a magnifying glass to see the blue stripes at all. There were three of them on one side of the strip which seemed to turn at right angles into the weft at regular intervals to continue on the opposite side. How could that be done?

The Research

Picton and Mack in African Textiles refer and defer to Venice Lamb’s exceptional field work in West African Weaving, and show in black and white a Liar’s Cloth from her collection – frustratingly indistinct for the non-expert. In her own book Lamb illustrates ‘an old Asante cloth with an inverted “liar” pattern. The liar pattern is fascinating: the warp thread is carried from side to side.’ In the small catalogue of the exhibition at the Halifax Museum of The Lamb Collection of West African Narrow Strip Weaving in 1973, there is yet another Liar’s in black and white. Hardly enough visual information to attempt such a feat on the loom! Nor were descriptions precise enough to help: Venice Lamb writes: ‘…there are a few devices which are rather harder to classify, such as the ‘floating warp’ technique used by Ashanti weavers to produce what they know as ‘liar’s cloth’, a kind of Greek fret pattern executed by shifting a warp stripe from one edge of the web to the other at regular intervals.’ And Kate Kent: ‘Ashanti weavers formerly produced…a handsome fabric called “liar's cloth” (Nkontompo ntoma), in which narrow lines meandered the length of a plain weave strip – either white lines on an indigo blue ground, or blue on a white ground. Blocks of weft-patterned design were woven over this warp pattern at regular intervals.’

It was the ethnographer R.S.Rattray in 1927 who established the name of the cloth as Liar’s. He made an extensive study of West African strip weaves, and put together a large collection of swatches, now in the British Museum, of both silk and cotton fabrics. Rattray’s swatch number 95 is a blue silk with two yellow and 2 red warp stripes and swatch 106 shows their meander into the weft and back on the opposite side. He elucidated the names given to the cloths according to the order and colour of warp stripes and attempting a description of the symbolism behind those names. His entry reads, ‘Nkontompo ntama’ (the liar’s cloth). The King of Ashanti is said to have worn this pattern when holding court, to confute persons of doubtful veracity who came before him.’ In 1969, another researcher Kate P. Kent was told that the shifting blue lines represented the liar’s speech.

Intriguing as it is, the name ‘liar’s’ and its meaning has survived, and it was interesting to find on the internet a mention of a Yale University thesis quite unrelated to textiles entitled ‘The Liar’s Cloth: Producing Veracity in the Victorian Courtroom’. Ethnographers seem to have been more exercised by the symbolism of the names than by the technique, and by their historical relation to status in the rigid hierarchy of the old Ashanti empire, where some combinations of stripes and patterns were reserved for royalty and nobility, the main sponsors of the weavers.

lcloth02

Traditional Kente cloth

Nowadays, after an eclipse lamented by writers of the 70s and 80s, it seems that narrow strip weaving is alive and well, whether worn as a mark of African identity or purchased by tourists, and the professional weavers formally trained by ‘masters’ in their workshops now even include women – witness a video recording produced in 1998 by the Open University as material for its Art and its

Histories course. The narrow strip loom of Ghana is well documented. The bundle of its 25 metres long warp is tensioned on a drag weight, its double heddle and reed, suspended from a frame, both pairs of heddles worked by the weaver’s feet. One heddle, the asatia, is threaded for the warp-faced tabby weave, the other, the asanan, threaded six by six ends, making itpossible to weave a weft-faced fabric at will and partially or completely cover the strip with decorative inlay left to the creativity of the weaver. Although some liar’s lines are worked along strips completely clear of inlay, the cloth that intrigued me had many indigo motifs and presented me with a double learning challenge. In The Art of the Loom Ann Hecht has a diagram showing the way to thread a modern four shaft loom to work like the double heddle loom – ground weave on shafts one and two, and weft-face on three and four, giving the same flexibility.

It seemed to me that in order to meander from side to side, the blue warps needed to be weighted independently at the back of the warp beam. To interlace with the weft, they had to be caught in heddles and go through the reed. My Texsolv heddle’s eye was large enough to take a small flat stick (a drinks stirrer) with the warp end wrapped on it, which I could manipulate in and out, use as a shuttle to weave in as weft, and return as warp, through empty heddles reserved on the opposite side, then back to their weight at the back of the loom. Not easy, but possible. Yet decidedly not the Ashanti way! More research was needed.

lcloth03

Floating warps?

Venice Lamb mentions a ‘floating warp’ technique in connection with the liar’s cloth. A few pairs of supplementary warps anchored independently on the cloth beam and weighted at the back would lie idle in the shed, neither held in the heddles or the reed, until lifted by the shuttle to appear as intermittent decoration on the cloth. As the liar’s lines weave continuously, it seemed to me that heddles were indispensable and floating warp not the solution. Another description suggested that ‘To make the meander pattern supplementary warps of liar's cloth served at times as weft. These were probably passed between the dents of the beater and through the eyes of the plain weave heddles when the loom was strung. They were thus part of regular plain weave when in the position of warps. When a warp pair was to be turned and used as a weft, it was cut to the appropriate length and woven in. The cut end would then fall free of the beater, but remain in the heddle eye. When it was to be re-utilized as warp again, it was pinned to the surface of the cloth – then woven in. (Ashanti weavers are accustomed to pinning any broken warp back into position in this fashion. The process outlined above was suggested by a young Ashanti weaver)’.

Convincing as this was, it failed to work for me, because I still had to move the blue warps from one side to the other, and I was left at each turn with four cut ends to darn back into the cloth in the usual way.

A theoretical solution

Not until I discovered the extraordinary survey and descriptive catalogue by Brigitte Menzel, mentioned in other works but never actually quoted or translated, Textilien Aus Westafrika, did I begin to see the light. Her swatches, like Rattray’s, relate mainly to the arrangement of warp stripes, but unlike him she concentrates, instead of the naming of cloths, on the exact thread count for each colour stripe. The swatch for ncontompo ntama shows 3 pairs of warps on the left, and the description says they are turned into the weft at 20cm intervals then vertically back into the warp. But it was the drawing that explained all. The warps are weighted, but at the front of the heddles! The blue threads are therefore wound on to the warp beam with the rest. And it dawned on me that there has to be two sets, one at each side of the strip. One set only weaves at a time, while the other rests attached to the weight, threaded in the heddles, but free of the reed. After 20cm of plain weave, one pair after another is cut off, freed of the reed and woven as weft to the appropriate point on the web to meet its opposite partner, which is detached from the weight, pinned on the cloth to be woven in on that side for the next 20 cm.

lcloth01

Looking at the real textile

I was fortunate enough to be able to test this theory on a genuine liar’s cloth thanks to John Gillow and the generosity of his friend Molly Hogg, who owns an old and damaged but very beautiful one. Like all Ashanti cloths, its web is very dense warp faced, about 80 epi (a lot more than I had guessed) of fine machine spun cotton. The blue pairs are equally fine, and only show faintly on the cloth. The strips have been sewn together with exquisitely small stitches and the arrangement of the strips aligning the liar’s lines back to back – so to speak – create a fretwork into which the indigo motifs are slotted. It is impossible to know whether it ever had a traditional heading of densely brocaded designs at each end as it is coarsely hemmed instead. Nor can one tell if it ever had more than the present 21 strips. Very few of the inlay motifs repeat many times, some only occur once, and this somehow reveals the skill of its imaginative weaver.

With a magnifying glass, it is possible to ascertain that the threads are cut at the turn from weft to warp. Sometimes there is a small but discernible gap, and one can detect the closely cut thread ends. They are held by the density of the web, in the same way as the brocading wefts, without knots or darning in. Perhaps these cuts are the lie, the deception; The line doesn’t ‘turn back into the warp’, it is not continuous. Instead it is replaced by a partner.

lcloth04

Detail of Claude’s completed liar’s cloth.

The practical solution

To put this new understanding into practice, I warped up a long 4 inches wide strip with very fine white silk at 72 epi and dyed some silk in indigo for the supplementary weft. I included three pairs of indigo warp stripes on each side of the strip, entering them all in the heddles normally. However only one set of blue stripes went through the reed, while the other was weighted down in front of the heddles. After 20cm I needed to go through the following steps to turn the liar’s lines:

1. wind on the weaving so there will be enough space in front of the heddles to manipulate the blue threads.

lcloth06

2. disengage the first blue pair from the weight, bring it up through the reed at the appropriate place and pin it on the woven cloth.

lcloth07

3. cut the opposite blue pair long enough to become weft . Disengage the cut end from the reed and weight it in front of the heddles with a second weight.

lcloth08

4. weave the two cut warps into the weft one after the other to meet the pinned threads Then weave with the ground weft until the next blue pair needs turning into weft and repeat steps 2 – 4.

lcloth09

Two weights are needed until all three pairs have changed sides. After weaving half an inch or an inch, remove all three pins and cut all loose threads lying on the surface of the weaving closely. Because the sett of the cloth is very high, the cut ends stay caught in the web. For the next 20cm one can concentrate on working the inlays patterns, before returning the liar’s lines to the opposite side once again.

It seems easy, so it is likely to be right. Another interpretation of the name Liar’s cloth is that anyone who says they can weave it is a liar: I am hoping I have disproved that saying.
